OVERVIEW
This small steel grease trap will fit in the smallest of spaces! Made from strong, durable mild steel this small grease trap can be fitted under your sink or outside
Thanks to the special epoxy coating and super low 285mm height, you have the choice to fit indoors or outdoors. Compact enough to fit underneath a sink unit this is an ideal size to accommodate the flow rate for a single bowl domestic sink. Cleaning access is quick and simple via the single screw lid.
Great Size Small Versatile Grease Trap
Measuring 350 x 300 x 285mm (w x l x h), the EPX20 is compact and perfectly sized to service one domestic sized sink bowl. From the moment wastewater begins to flow fats, oils and grease (FOG’s) will start to collect safely and not block your drains.
Ideal for those with a low usage and wanting to prevent food oils and grease from entering the drain system. This manual Grease Trap runs entirely using the flow of water. Internal directional baffles ensures waste water easily escapes whilst allowing fats, oils and grease to cool, rising to the surface and staying within the trap. Routinely clean the trap by simply opening the centre screw, scooping surface FOG’s and clean the sides and lid of the trap. It is advised to keep supporting documentation of cleaning.
PRODUCTS DETAILS
Description
20 Litre Grease Trap
This 20 litre grease trap is a compact and reliable solution for managing fats, oils and grease in domestic kitchens and small food preparation areas. It helps prevent blocked drains and supports responsible wastewater management without the high costs associated with commercial grease systems. If you need an efficient and affordable way to control FOG build up, this 20 litre unit is an excellent choice.
You can also browse our full range of options in the
commercial grease trap collection.
Key Features
- Epoxy coated steel body suitable for indoor or outdoor installation
- 20 litre capacity
- Flow rate of 14 litres per minute
- 50mm inlet and outlet connections
- 4 kg grease holding capacity
- Ideal for one small or domestic sink bowl
- Secure airtight lid seal to reduce odours
- Anti rust and corrosion resistant construction
- Compatible with standard multi fit rubber connectors
- Model EPX20
- Size 350 x 300 x 285 mm
- Suitable for up to 40 meals per day
Designed for Smaller Kitchens
At The Grease Trap Store we provide durable stainless steel and epoxy coated grease management systems designed for long term performance. This 20 litre grease trap is ideal for small spaces and can be installed beneath a sink, outdoors or in other areas where flexibility is required. The epoxy coating improves durability and protects the unit from weathering.
Choosing the correct size is important. Selecting a trap that is too small for your water flow can reduce separation efficiency and may lead to slow drainage or backups. This 20 litre grease trap has been developed to handle the flow rate of a domestic sink while maintaining effective grease separation.
Flexible Installation Options
This unit is designed to suit a variety of installation locations. It can be placed above ground or underground and features a thick lid seal to keep odours contained. The single bolt lid allows easy access for routine cleaning without the need for heavy lifting.
Cost Effective Grease Control
Passive grease traps are one of the most economical ways to manage FOGs. With no electrical parts or replacement filters, this system provides ongoing performance at minimal cost. Regular inspection is recommended during the first few weeks and the trap should be emptied whenever the collected grease reaches the recommended level.
Users may choose to work with a local grease trap cleaning service or include the cleaning process in their regular maintenance schedule. Disposal should always follow local authority guidelines.
Built for UK Wastewater Requirements
All grease traps supplied by The Grease Trap Store meet UK standards and are supported by a five year manufacturer defect warranty. This 20 litre grease trap complies with Building Regulations Part H (2.21) and provides dependable protection for your drainage system.
Fast Delivery Available
Order your 20 litre grease trap today and benefit from fast dispatch options. This compact unit is ideal for homeowners, small cafés and any setting where an affordable and effective grease management solution is required.
